Unswitched Fused Spur & Flex Outlet Click Deco 13A White VPSC050WH
£9.99
Sale price
£9.99
Regular price
Skip to product information
Unswitched Fused Spur & Flex Outlet Click Deco 13A White VPSC050WH
£9.99
Sale price
£9.99
Regular price
This is part of liquidation stock please check out other listings
- Click Scolmore
- Deco Victorian
- Fused Connection Unit with Optional Flex Outlet
- Victorian Style Plate
- Satin Chrome Finish
- Supplied with white gasket
- Style: Victorian
- Finish: Satin Chrome
- Insert Colour: White
- Gasket Colour: White
- Gang (Size): 1
- Plate Dimensions (W) (mm): 88
- Plate Dimensions (H) (mm): 88
- Plate Dimensions (D) (mm): 8
- Plate Dimensions (mm): 88 (W) x 88 (H) x 8 (D)
- Dimensions With Gasket (mm): 91 (W) x 91 (H) x 9 (D)
-
Materials:
- Front Plate: Stainless Steel
- Insert, Fuse Drawer & Housing: Urea
- Terminals: Brass
- Terminal Screws: Steel & Yellow Passivated
- Internal Busbars: Formed Pressed Brass
- Earth Strap: Mild Steel
- Gasket: Nylon
- Rated Voltage (V~) (Ue): 250
- Frequency (Hz): 50
- Load Rating (A): 13
- Fuse Fitted Rating (A): 13
- Fuse Fitted Rating & Type: 13A (BS 1362)
- Terminal Size (mm): Ø5
- Terminal Torque Value (Nm): 2
- Terminal Capacity - Solid (mm²): 3 x 2.5 or 2 x 4
- Termination Type: Screw
- Minimum Back Box Depth (mm): 25
- Plate Fixing Centres - Horizontal (mm): 60.3
- Switched: No
- Twin Earth Terminal: Yes
- Flex Outlet Available: Yes
- Flex Outlet Dimension (mm): Ø10
- Flex Outlet Location: Front of Plate
- Product Marking: Fused
- Ingress Protection: IP20
- Operational Temperature (°C): -5 to +40
